RD1616DC ultra low power negative ion generation module

RD1616DC is a very lightweight and ultra-low power negative ion generation module. This module generates negative ions through powerful digital control technology and negative ion generation algorithm, and obtains a large number of negative ions with the lowest energy consumption through powerful control to achieve high negative ion conversion efficiency. It can also control not to produce ozone gas.

RD1616DC is our patented product. It is not a simulated resonance of the working principle of traditional negative ion generation, but a new state technology product. It can produce high concentration negative (oxygen) ions with the highest efficiency, saving power and small volume. Moreover, the associated ozone concentration is far lower than that of most products on the market. The ozone concentration is only 0.006ppm, much lower than 0.05ppm specified by FDA, It is the safest negative ion generation device.

产品详情

Product features:

1. In an empty space at a distance of 15 cm, the negative ion concentration can reach up to 16 million negative ions per cubic centimeter.

2. In the empty space 15 cm away from the negative ion emission port, the negative ion concentration can reach 670 million negative ions per cubic centimeter.

3. Very small module size: 15mm (L) x 15mm (W) x 7mm (H))

4. Have stable digital control

5. Concomitant ozone concentration limits in accordance with FDA requirements

6. Very low power consumption, very suitable for mobile devices

Power consumption (uninterrupted operation) < 8mwh

Power consumption (intermittent operation) < 4mwh

7. Negative ion discharge voltage range: 2.5KV ~ 5kV

8. Wide voltage input range: dc3.3v ~ dc30v

9. Working temperature range: - 10 ℃ ~ 65 ℃

10. Negative ion generation medium: carbon brush and metal needle

Product application:

● wearable anion air purifier (necklace, headset, electronic mask)

● desk type anion air purifier

● can be combined with the following devices

1. Water sprayer

2、 Fan (USB Fan)

3、 Hair dryer

4、 Air conditioning

5、 Safety helmet
